TM 9--2350--292--10
0074 00--3
STARTING MAIN ENGINE IN EXTREME COLD WEATHER +32°F TO --25°F
(0°C TO --31°C) -- CONTINUED
0074 00
CAUTION
Do not hold the START button in for longer than 60 seconds. Release START button and
engine PREHEAT switch. Repeat steps 7 and 8 until engine runs. If engine does not start
after third try, troubleshoot (WP 0087 00).
If the SYSTEM WARNING indicator does not go out 20 seconds after engine starts, stop
engine and notify unit maintenance. Failure to comply may result in damage to equipment.
9. Depress accelerator pedal (7) to its full travel. Push and hold START button (8) until engine runs.
10. Release START button (8) after the tachometer gauge (9) indicates an engine speed of 300 RPM. Keep
accelerator pedal fully depressed until the engine quickly responds to the accelerator pedal adjustments (throttle
response). The systems warning indicator (10) should illuminate and remain illuminated no longer than 20
seconds.
8
10
9
7
