TM 9--2350--292--20--1 0295 00--1 WIRING HARNESS 3W143 REPLACEMENT 0295 00 THIS WORK PACKAGE COVERS: Removal, Installation INITIAL SETUP: Tools and Special Tools General mechanic’s tool kit (item 1, WP 0717 00) Materials/Parts Lockwashers (16) (item 58, WP 0718 00) Lockwasher (item 38, WP 0718 00) Lockwashers (2) (item 11, WP 0718 00) Marker tags (item 49, WP 0716 00) Equipment Conditions Vehicle MASTER switch OFF (TM 9--2350--292--10) Battery power disconnected (WP 0256 00) Engine deck assembly removed (WP 0417 00) References TM 9--2350--292--10 Removal NOTE Tag all electrical connections and electrical leads prior to removal to aid in installation. The following legend identifies attachment points for each connection. 1.   Remove wiring harness (1) and attaching hardware, at the following attachment points: Item No. 3W143 Connector/Lead/Wire From Connector/Lead/Wire Component Location 2 Connector P1 Engine Disconnect Bracket Engine Compartment (Left Side) 3 Connector J1 3W180 Connector P2 Engine Compartment (Near APU Regulator) 4 3W143 GND Negative Bus E--3 Engine Compartment (Left Side) 5 3W143 GND Negative Bus E--3 Engine Compartment (Left Side) 6 3W143 GND Negative Bus E--3 Engine Compartment (Left Side) 7 3W143 GND Negative Bus E--3 Engine Compartment (Left Side) 8 Connector P2 Bulkhead Connector J2 Engine Compartment (Left Side) 9 Wire 31 Fuel Level Sensor Engine Compartment (Right Side, Near Bulkhead) 10 Connector J2 3W132 Connector P2 Engine Compartment (Left Side, Near Bulkhead)
