TM 9--2350--292--20--1 0300 00--1 WIRING HARNESS 3W202 REPLACEMENT 0300 00 THIS WORK PACKAGE COVERS: Removal, Installation INITIAL SETUP: Tools and Special Tools General mechanic’s tool kit (item 1, WP 0717 00) Materials/Parts Assembled washer screws (3) (item 424, WP 0718 00) Self--locking nuts (6) (item 274, WP 0718 00) Self--locking nut (item 120, WP 0718 00) Lockwasher (item 127, WP 0718 00) Silicone adhesive (item 81, WP 0716 00) Self--locking nut (item 251, WP 0718 00) Materials/Parts--Continued Lockwasher (item 18, WP 0718 00) Electrical tiedown strap (item 382, WP 0716 00) Marker tags (item 49, WP 0716 00) Lockwasher (item 9, WP 0718 00) Lockwasher (item 10, WP 0718 00) Lockwashers (5) (item 78, WP 0718 00) Equipment Conditions Powerpack removed (WP 0188 00) Personnel Required Two Removal NOTE Tag all electrical connections and electrical leads prior to removal to aid in installation. The following legend identifies attachment points for each harness connector, wire connector or wire terminal lug. 1.   Remove wiring harness (1) and attaching hardware at the following attachment points: Retain attaching hardware for installation. WIRING HARNESS 3W202 ATTACHMENT POINTS Item No. Connector Plug/ Wire Connector/ Wire Terminal Lug From Connector/Lead/Wire Component Engine Location 2 Wire T terminal lug Starter solenoid motor terminal Left side near starter motor 3 Wire M terminal lug Starter motor ground terminal Left side at starter motor 4 Wire 14B terminal lug Starter solenoid B+ terminal Left side near starter motor 5 Wire 14D terminal lug Starter solenoid switch terminal Left side near starter motor 6 Wire S terminal lug Starter solenoid switch terminal Left side near starter motor 7 Connector plug Low voltage protection module re- ceptacle Left side in front of starter motor 8 Connector plug Left manifold pre--heat coil recep- tacle Lower left side 9 Connector plug Fuel water separator control recep- tacle Left side in front of low voltage protection module
