TM 9--2350--292--20--1 0187 00--114 0187 00 PREVENTIVE MAINTENANCE CHECKS AND SERVICES INCLUDING LUBRICATION INSTRUCTIONS -- CONTINUED TABLE 3 PREVENTIVE MAINTENANCE CHECKS AND SERVICES INCLUDING LUBRICATION INSTRUCTIONS, SEMIANNUALLY -- CONTINUED ITEM NO. NOT FULLY MISSION CAPABLE IF: PROCEDURE LOCATION ITEM TO CHECK/ SERVICE INTERVAL SEMIANNUALLY EXTERIOR 26 Wheels, Arms and Hubs a. Open armor skirt panels (TM 9--2350--292--10). WARNING NOTE Prior to performing this check, ve- hicle must be operated for 5--10 minutes. b. Immediately after vehicle operation, feel all wheel hubs (1) cautiously for noticeable variations of temperature between like components. An overheated hub indicates maladjustment, inadequate lubrication or damaged bearing. c. Visually inspect arms (2) and hubs (1) for lubricant leaks. Replace seals and/or gaskets where leaks are evident (WP 0388 00, WP 0395 00, WP 0387 00 and WP 0394 00). d. Check for loose or missing mounting screws (3). Replace missing mounting screws (3). Torque mounting screws (3) to 245--270 lb--ft (334--366 N•m) with torque wrench (item 9, WP 0717 00). Any overheated wheel hubs, lubricant leaks, loose or missing mounting hardware. 1 2 3 ARMOR SKIRTS REMOVED FOR CLARITY
