TM 9--2350--292--20--2
BRAKE ACCUMULATOR REPLACEMENT -- CONTINUED
0372 00
Installation
1. Install accumulator (4) in hull with four screws (5), four new lockwashers (6) and two clamps (7).
2. Apply a thin even coat of clean lubricant to new preformed packing (3).
3. Install adapter (2), new preformed packing (3) and hose assembly (1) on accumulator (4).
4. Charge accumulator, if required (WP 0373 00).
5. Start vehicle (TM 9--2350--292--10) to pressurize system and check for leaks.
3
1
2
6
5
7
4
NOTE
FOLLOW--ON MAINTENANCE:
Install subfloor plates #15 and #18 (WP 0454 00)
END OF TASK
0372 00--3/4 blank
