MANIFOLD HEATER FUEL FILTER AND SOLENOID REPLACEMENT

TM-9-2350-292-20-1 Carrier Ammunition Tracked M992A1(NSN 2360-01-362-3021) EIC:AE6 Manual
Page Navigation
1105

TM 9--2350--292--20--1 0223 00--1 MANIFOLD HEATER FUEL FILTER AND SOLENOID REPLACEMENT 0223 00 THIS WORK PACKAGE COVERS: Removal, Installation INITIAL SETUP: Tools and Special Tools General mechanic’s tool kit (item 1, WP 0717 00) Materials/Parts Lockwashers (2) (item 18, WP 0718 00) Lockwashers (2) (item 58, WP 0718 00) Pressure sensitive tape (item 41, WP 0716 00) Dry--cleaning solvent (item 1, WP 0716 00) Equipment Conditions Front engine deck grilles removed (TM 9--2350--292--10) For maintenance of manifold heater fuel filter Powerpack removed (WP 0188 00) References TM 9--2350--292--10 WARNING NOTE The following steps provide for a complete replacement of the manifold heater fuel filter and solenoid. Perform only those steps necessary for maintenance of defective parts. Removal 1. Disconnect two fuel lines (1) from tee (2). Figure 29 POWERPACK REMOVED FOR CLARITY 1 1 2
