ENGINE BATT/GEN GAUGE READS IN YELLOW OR LOWER RED REGION
WITH MAIN ENGINE RUNNING -- CONTINUED
0082 00
D
Perform STE--ICE--R test 67
(TM 9--4910--571--12&P) while running engine.
Record results.
Is VTM reading between 27 and 30 V dc static?
no
yes
CONTINUED ON NEXT PAGE
Go to Step G.
Perform STE--ICE--R test 75
(TM 9--4910--571--12&P) and record results.
no
yes
Check battery terminals
and connections for
corrosion and check
electrolyte levels.
Recharge batteries
(TM 9--2350--292--10) if
necessary and run test
again. If test fails, go to
Step J.
E
Is VTM reading less than 16.7 milliohms?
Go to WP 0043 00.
CONTINUED FROM STEP C
CONTINUED FROM STEPS B AND C
Perform STE--ICE--R test 73
(TM 9--4910--571--12&P) and record results.
no
yes
F
Is VTM reading less than 8.33 ohms?
Go to Step J.
