TM 9--2350--292--20--10231 00--1ENGINE AND TRANSMISSION OIL COOLER REPLACEMENT0231 00THIS WORK PACKAGE COVERS:Removal, InstallationINITIAL SETUP:Tools and Special ToolsGeneral mechanic’s tool kit (item 1, WP 0717 00)Suitable container (2.0 gal. min. (7.5 L))Automotive adjustable wrench (item 22, WP 0717 00)Materials/PartsLockwashers (2) (item 356, WP 0718 00)Lockwashers (6) (item 2, WP 0718 00)Gaskets (2) (item 384, WP 0718 00)Preformed packings (2) (item 311, WP 0718 00)Gaskets (2) (item 383, WP 0718 00)Self--locking nut (item 283, WP 0718 00)Parts kit (item 423, WP 0718 00)Equipment ConditionsPowerpack removed (WP 0188 00)Engine oil cooler vent hoses removed(WP 0200 00)For maintenance of engine oil coolerTransmission oil cooler lines removed(WP 0345 00)For maintenance of transmission oil coolerWiring harness 3W202 wire 530B discon-nected from manifold heater fuel solenoid(WP 0300 00)Air intake elbows removed (WP 0191 00)Personnel RequiredTwoNOTEThere is a left and a right side engine and transmission oilcooler. Both are replaced in the same manner. This taskreplaces only the right side engine and transmission oilcooler.Perform Removal steps 1 through 9 and 15 and Installa-tion steps 6 through 14 for maintenance of left or rightengine oil cooler.Perform Removal steps 10 through 15 and Installationsteps 1 through 5 for maintenance of left or right trans-mission oil cooler.
