TM 9--2350--292--20--1
0281 00--2
SPOTLIGHT REPAIR -- CONTINUED
0281 00
Disassembly--Continued
8. Remove bushing (31) from tube (32).
9. Loosen screw (33), remove tube (32) and outside tube (34) from housing (35).
10. Inspect parts for damage and replace as required.
Figure 92
1
2
3
4
5
6
7
8
9
11
12
13
16
17
15
18
19
20
21
22
23
24
25
26
27
28
29
30
31
33
34
35
32
14
FORWARD
10
