TM 9--2350--292--20--10133 00--2TRANSMISSION OIL TEMPERATURE GAUGE FAILS TO OPERATE --CONTINUED0133 00CIs 24 V dc present?CONTINUED FROM STEP Anoyes1. Remove switch panel from bracket andreconnect ground strap to switch panel(WP 0242 00).2. Disconnect lead 10 from CB6.3. Turn MASTER switch ON(TM 9--2350--292--10).4. Place red multimeter lead in lead 10 socketconnector and black to ground. Check forvoltage.5. Turn MASTER switch OFF(TM 9--2350--292--10).Go to WP 0131 00 and troubleshootwiring harness 4W105 P1 lead 10 fromswitch panel. Verify fault is corrected.Is 24 V dc present?noyes1. Disconnect harness 3W202 lead 324 fromtransmission oil temperature transmitter.2. Turn MASTER switch ON(TM 9--2350--292--10).3. Place multimeter red lead in lead 324transmitter connector socket and black leadto ground. Check for voltage.4. Turn MASTER switch OFF(TM 9--2350--292--10).Replace transmitter (WP 0348 00).Verify fault is corrected.CONTINUED FROM STEP BCONTINUED ON NEXT PAGEIs 24 V dc present?1. Disconnect lead 25/27 from CB6.2. Place one multimeter lead on each CB6connector pin. Check for continuity.3. Reconnect leads 10 and 25/27 to CB6.DEnoyesReplace CB 6 (WP 0242 00). Verifyfault is corrected.
