TM 9--2350--292--20--2
0629 00--1
AUXILIARY POWER UNIT AIR INTAKE ADAPTER AND GLOW PLUG
REPLACEMENT (HATZ)
0629 00
THIS WORK PACKAGE COVERS:
Removal, Installation
INITIAL SETUP:
Tools and Special Tools
General mechanics tool kit (item 1, WP 0717 00)
Torque wrench (item 2, WP 0717 00)
Materials/Parts
Adhesive (item 29, WP 0716 00)
Lockwashers (4) (item 467, WP 0718 00)
Gasket (item 479, WP 0718 00)
Equipment Conditions
APU air intake hose removed (WP 0621 00)
APU lead assembly 3W732 removed (WP 0658 00)
Removal
1. Remove glow plug (1) from air intake adapter (2).
2. Remove four screws (3), four lockwashers (4), gasket (5) and air intake adapter (2) from APU. Discard lockwash-
ers and gasket.
3. Inspect all parts for damage and replace as required.
1
2
3
4
5
