TM 9--2350--292--20--10240 00--3ENGINE STARTER, CRADLE AND BRACKET REPLACEMENT -- CONTINUED0240 00Removal--ContinuedNOTEKeep cradle attached to starter motor to provide extrasupport while disengaging starter from powerpack.5. Remove four screws (22) and four flat washers (23) from cradle (24).6. Remove three self--locking nuts (25) from adapter bolts (26). Discard self--locking nuts.WARNING7. Position suitable wooden blocks under starter (27) assembly for support.8. Remove starter (27) and mounting gasket (28) from starter adapter. Discard gasket.CAUTIONUse care in removing cradle to avoid damaging black so-lenoid to motor ground wire.9. Remove two nuts (29), two clamping bars (30), U--bolt (31) and cradle (24).10. Remove four screws (32), four flat washers (33) and angle bracket (34) from powerpack.11. Inspect parts for damage and replace as required.Figure 4629302631243423223233282527
