ENGINE CRANKS AT NORMAL SPEED BUT WILL NOT START (cont)

ENGINE CRANKS AT NORMAL SPEED BUT WILL NOT START (cont) - TM-9-2350-292-20-1_236

ENGINE CRANKS AT NORMAL SPEED BUT WILL NOT START (cont) - TM-9-2350-292-20-1_238

TM-9-2350-292-20-1 Carrier Ammunition Tracked M992A1(NSN 2360-01-362-3021) EIC:AE6 Manual
Page Navigation
193

TM 9--2350--292--20--1 0042 00--4 ENGINE CRANKS AT NORMAL SPEED BUT WILL NOT START -- CONTINUED 0042 00 f. ENGINE -- CONTINUED (2) ENGINE CRANKS AT NORMAL SPEED BUT WILL NOT START -- CONTINUED Does fuel flow freely? no yes F Does fuel flow from air bleeder valve? 1. Disconnect mechanical fuel pump fuel line from fuel/water separator. 2. Place fuel line over a suitable container. 3. Turn MASTER switch and fuel pump switches ON and crank engine (TM 9--2350--292--10). 4. Turn MASTER switch and fuel pump switch OFF (TM 9--2350--292--10). G no yes CONTINUED FROM STEP E Replace mechanical fuel pump (WP 0206 00). Verify fault is corrected. 1. Reconnect mechanical fuel pump fuel line to fuel/water separator. 2. Loosen air bleeder valve on top of fuel/water separator. 3. Crank engine (TM 9--2350--292--10). Replace fuel/water separator elements (WP 0220 00). Verify fault is corrected. CONTINUED ON NEXT PAGE
